Description
| Factory No. | AHG-314 | ||
| OE | 486 | ||
| Teeth | 9 | Gear Diameter | 25.8 |
| Height | 47/49 | Inner Diameter | 10 |
| Grooves No. | 12.1 | Outer Diameter | 47.8 |
| Rotation | CW | ||
| Factory No. | AHG-314 | ||
| OE | 486 | ||
| Teeth | 9 | Gear Diameter | 25.8 |
| Height | 47/49 | Inner Diameter | 10 |
| Grooves No. | 12.1 | Outer Diameter | 47.8 |
| Rotation | CW | ||
